Name: DLINK SWITCH 8PORT PoE GIGABIT LAN PORTS, PoE BUDGET 64W, EASY SMART MANAGED L2, VLAN, AUTO MDI/MDIX, METAL CASE, FANLESS, DESKTOP, 5YW
SKU: DGS-1100-08PV2
Availability: InStock

DLINK SWITCH 8PORT PoE GIGABIT LAN PORTS, PoE BUDGET 64W, EASY SMART MANAGED L2, VLAN, AUTO MDI/MDIX, METAL CASE, FANLESS, DESKTOP, 5YW

€97.63

8-Port Gigabit PoE Smart Managed Switch

In stock

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	8
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
10G support	No
Port mirroring	Yes
Flow control support	Yes
Link aggregation	Yes
Broadcast storm control	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
VLAN support	Yes
Virtual LAN features	Port-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs	4094
MAC address table	4096 entries
Switching capacity	16 Gbit/s
Forwarding rate	11.9 Mpps
Jumbo frames support	Yes
Jumbo frames	9216
IGMP snooping	Yes
Loop protection	Yes
Multicast support	Yes
Rack mounting	No
Product colour	Black
Certification	FCC Class B, CE Class B, VCCI Class B, BSMIcUL, CE LVD, CB, BSMI
Flash memory	2 MB
Fanless	Yes
Power supply included	Yes
AC input voltage	100 – 240 V
AC input frequency	50 – 60 Hz
Power consumption (max)	77.9 W
Power over Ethernet (PoE)	Yes
Operating temperature (T-T)	0 – 40 °C
Storage temperature (T-T)	-40 – 70 °C
Operating relative humidity (H-H)	0 – 90%
Storage relative humidity (H-H)	0 – 95%
Heat dissipation	265.85 BTU/h
Width	171 mm
Depth	97.8 mm
Height	28.6 mm
Harmonized System (HS) code	85176990
Queue scheduling algorithms	SP, Weighted Round Robin (WRR)
LED indicators	Yes
Power over Ethernet plus (PoE+) ports quantity	8
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	64 W
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Number of queues	4
Full duplex	Yes
Auto MDI/MDI-X	Yes
Sustainability compliance	Yes
Half duplex	Yes
Mean time between failures (MTBF)	786841 h
Weight	430 g
Compliance certificates	CE, RoHS
Manufacturer	D-Link
