Projector brightness
|
4600 ANSI lumens
|
|
Projection technology
|
3LCD
|
|
Manufacturer
|
EPSON
|
|
Projector native resolution
|
1080p (1920×1080)
|
|
Contrast ratio (typical)
|
2500000:1
|
|
Native aspect ratio
|
16:9
|
|
Screen size compatibility
|
787.4 – 7874 mm (31 – 310")
|
|
Number of colours
|
1.07 billion colours
|
|
Vertical scan range
|
192 – 240 Hz
|
|
Keystone correction, vertical
|
±30°
|
|
Light source type
|
Laser
|
|
Service life of light source
|
20000 h
|
|
Focal length range
|
18.2 – 29.1 mm
|
|
Zoom capability
|
Yes
|
|
Zoom type
|
Manual
|
|
Zoom ratio
|
1:1.62
|
|
Throw ratio
|
1.32 – 2.12:1
|
|
Offset
|
1000%
|
|
VGA (D-Sub) ports quantity
|
3
|
|
HDMI ports quantity
|
2
|
|
USB 2.0 ports quantity
|
2
|
|
Serial interface type
|
RS-232C
|
|
AC (power) in
|
Yes
|
|
Ethernet LAN
|
Yes
|
|
Wi-Fi
|
Yes
|
|
Noise level
|
37 dB
|
|
Noise level (economic mode)
|
27 dB
|
|
On Screen Display (OSD)
|
Yes
|
|
Password protection
|
Yes
|
|
Built-in speaker(s)
|
Yes
|
|
RMS rated power
|
16 W
|
|
Product type
|
Standard throw projector
|
|
Cable lock slot
|
Yes
|
|
Cable lock slot type
|
Kensington
|
|
Power source
|
AC
|
|
Power consumption (typical)
|
199 W
|
|
Power consumption (standby)
|
0.5 W
|
|
Power consumption (max)
|
260 W
|
|
AC input voltage
|
220 – 240 V
|
|
AC input frequency
|
50 – 60 Hz
|
|
Operating relative humidity (H-H)
|
20 – 80%
|
|
Weight
|
4.15 kg
|
|
Width
|
325 mm
|
|
Depth
|
299 mm
|
|
Height
|
90 mm
|
|
Package weight
|
5.93 kg
|
|
Remote control included
|
Yes
|
|
Batteries included
|
Yes
|
|
Cables included
|
HDMI, Power
|
|
Keystone correction, horizontal
|
±30°
|
|
Heat dissipation
|
884 BTU/h
|
|
Focus
|
Manual
|
|
Aperture range (F-F)
|
1.51 – 1.77
|
|
Full HD
|
Yes
|
|
USB 2.0 Type-A ports quantity
|
1
|
|
HDCP
|
Yes
|
|
Country of origin
|
Philippines
|
|
Product colour
|
White
|
|
Power consumption (economy mode)
|
144 W
|
|
Storage temperature (T-T)
|
-10 – 60 °C
|
|
Storage relative humidity (H-H)
|
10 – 90%
|
|
Package width
|
380 mm
|
|
Package depth
|
495 mm
|
|
Package height
|
190 mm
|
|
Projector brightness (economic mode)
|
3200 ANSI lumens
|
|
Service life of light source (economic mode)
|
30000 h
|
|
Video processing
|
10 bit
|
|
Video colour modes
|
Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Presentation, sRGB
|
|
Composite video in
|
1
|
|
Ethernet LAN (RJ-45) ports
|
1
|
|
Placement
|
Ceiling, Desktop, Floor, Wall
|
|
Bundled software
|
Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management
|
|
Quantity per pack
|
1 pc(s)
|
|
Products per pallet
|
44 pc(s)
|
|
Products per pallet (UK)
|
66 pc(s)
|
|
Supported network protocols
|
HTTPS, IPv6, SNMP, ESC/VP.net, PJLink
|
|
Products per pallet layer
|
4 pc(s)
|
|
Products per pallet layer (UK)
|
6 pc(s)
|
|
Audio (L/R) in
|
2
|
|
Audio (L/R) out
|
1
|
|
Miracast
|
Yes
|
|
Projection distance (wide)
|
0.9 – 9.1 m
|
|
Wi-Fi standards
|
Wi-Fi 5 (802.11ac)
|
|
Air filter
|
Yes
|
|
Microphone in
|
Yes
|
|
Screen mirroring
|
Yes
|
|
Projection modes
|
Ceiling, Front
|
|
Audio Return Channel (ARC)
|
Yes
|
|
Contrast ratio (dynamic)
|
5000000:1
|
|
Other features
|
AV Mute Slide, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Direct Power on/off, Document Camera Compatible, Edge Blending, Home Screen,
|
|
Interface
|
USB 2.0-A, USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wi-Fi Direct, VGA in (2x), VGA out, Composite in, Miracast, Jack plug out, Jack plug in (2x), Cinch audio out, Microphone inp
|
|
Security features
|
Kensington lock, Security bar, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
|
|
Control panel
|
0.62 inch with C2 Fine
|
|
Box contents
|
HDMI Cable, Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, Warranty card
|
|
Option type
|
Air filter, Ceiling mount, Connection and control box, Document camera, External Speaker, Safety wire set, Suspension adapter, WP System – ELPWP10, Wall mount, Wireless transmitter – ELPWT01
|
|
Mobile app support
|
Yes
|
|
Pallet gross length
|
120 cm
|
|
Pallet gross width
|
80 cm
|
|
Pallet gross height
|
2.24 m
|
|
Pallet length (UK)
|
120 cm
|
|
Pallet height (UK)
|
2.24 m
|
|
Colour modes (2D)
|
Cinema, Dynamic, sRGB, Game, Presentation
|
|
Power consumption
|
201 Watt (Normal On-Mode), 260 Watt (Normal Peak-mode), 191 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby)
|
